Precision engineering behind every keystroke
SharpX led the circuit and PCB layout development for Nomad, a BLE mechanical keyboard designed for makers who won't compromise on feel or flexibility.
The build called for advanced electronics inside a compact footprint: multi-device Bluetooth switching, hot-swappable switch sockets for both ANSI and ISO layouts, a 1.9-inch crystal-clear display, tactile rotary encoders, and a power system engineered for reliable all-day use.
Every schematic and PCB layout followed industry-standard manufacturing protocols from the start — keeping bulk production straightforward and per-unit cost under control without touching the design intent.
Feature set
REV. 01Inside the build
Six production shots covering the assembled unit, PCB layout, and key mechanism detail. Click any tile to open full size.
Schematic design
Full circuit schematics built for manufacturability and long-term maintainability.
PCB layout
Dense, production-ready layouts that hold signal integrity under RF constraints.
Power systems
Battery charging and power management circuits tuned for daily-use reliability.
DFM review
Design-for-manufacture checks that keep bulk production cost-effective at scale.
